Kuka KR30 Nine Axis Arc Welding Robot With H Kuka Shape Positioner Arc Welding , Spotwelding , Stud Welding

Kuka KR30 Nine Axis Arc Welding Robot With H Kuka Shape Positioner Arc Welding , Spotwelding , Stud Welding

kuka KR30 Arc welding robot

kuka KR30 Spotwelding Robot

kuka KR30 nine axis Robot

Place of Origin:

Germany

Brand Name:

kuka

Model Number:

KUKA KR30

Contact Us
Request A Quote
Kuka KR30 Nine Axis Arc Welding Robot With H Kuka Shape Positioner Arc Welding , Spotwelding , Stud Welding
Kuka KR30 Nine Axis Arc Welding Robot With H Kuka Shape Positioner Arc Welding , Spotwelding , Stud Welding Kuka KR30 Nine Axis Arc Welding Robot With H Kuka Shape Positioner Arc Welding , Spotwelding , Stud Welding
Product Details
Model:
KUKA KR30
Range:
2033mm
Payload:
30kg
Payment & Shipping Terms
Minimum Order Quantity
1 PC
Price
0USD-1200USD
Packaging Details
wooden packing
Delivery Time
7 days
Payment Terms
L/C, T/T
Supply Ability
50 PCS
RELATED PRODUCTS
Good price KUKA KR 210 R3100 Ultra C4 Press tending , Palletising , Painting Polishing ,Machining Waterjet cutting 210 Kg 3100 mm online Video

KUKA KR 210 R3100 Ultra C4 Press tending , Palletising , Painting Polishing ,Machining Waterjet cutting 210 Kg 3100 mm

Get Best Price
Good price Yaskawa MA1900 Used Robotic Arm 6 Axis Robot Robotic Arm For Welding online Video

Yaskawa MA1900 Used Robotic Arm 6 Axis Robot Robotic Arm For Welding

Get Best Price
Good price Yaskawa Spraying Used Robotic Arm EPX2900 Working Range 2900mm Payload 20kg online Video

Yaskawa Spraying Used Robotic Arm EPX2900 Working Range 2900mm Payload 20kg

Get Best Price
Good price Used Yaskawa EPX2900 Fully Automatic 6 Axis Spraying Robot Arm With Explosion Proof Device online Video

Used Yaskawa EPX2900 Fully Automatic 6 Axis Spraying Robot Arm With Explosion Proof Device

Get Best Price
Contact Us
+8618123897892
dai155129291@gmail.com
Contact Now
Product Description

Kuka 9 axis welding system consisting of:

- 1 x Kuka KR 30/2 six axis industrial robot with KRC2 controller, 2033 mm arm reach and 30 kg payload.

- 1 x three axis welding positioner H shape (automatic load and unloading station) with a loading capacity of 500 kg. It has 2000 mm between head and tail

- 1 x SKS 400, 400A or Fronius TPS4000

This robot is equipped with the KRC2 controller, 5.4.14 software version under WinXP

The KR C2 robot controller makes programming easier with its Microsoft Windows interface. It is expandable, can be integrated into networks via a bus, and contains ready-made software packages.

KR C2 features:

  • Open, network-capable PC technology
  • 2 free slots for external axes
  • DeviceNet and Ethernet slots for common bus systems (e.g. INTERBUS, PROFIBUS, DeviceNet) provided as standard
  • Motion profile function for optimal interaction between the individual robot motors and their velocity
  • Floppy disk and CD-ROM drives for data backup
  • Facilities such as remote diagnosis via the Internet
  • Simple operation and programming via KUKA Control Panel (KCP) with Windows user interface
  • Compact control cabinet
  • Ergonomic KUKA Control Panel (KCP)

Applications

Arc welding , Spotwelding , Stud welding

General specifications

  • Maximum Load of Robot: 30 Kg
  • Maximum horizontal arm reach: 2033 mm
  • Repeatability: 0.06 mm
  • Controller: KRC2

Robot Motion Speed

  • Axis 1: 140º/s
  • Axis 2: 126º/s
  • Axis 3: 140º/s
  • Axis 4: 260º/s
  • Axis 5: 245º/s
  • Axis 6: 322º/s

Motion range

  • Axis 1: +-185º
  • Axis 2: +35º to -135º
  • Axis 3: +158º to -120º
  • Axis 4: +-350º
  • Axis 5: +-119º
  • Axis 6: +-350º
